X6X-ORN
NVIDIA® Jetson Orin Edge AI Compact Rugged Embedded System
DFI X6X-ORN – IP67 Fanless Edge AI System with NVIDIA® Jetson Orin™
- NVIDIA® Jetson Orin Nano™ / NX module support (MAXN SuperMode)
- IP67 waterproof & dustproof ruggedized fanless design
- Wide operating temperature: -20°C to 60°C
- Camera connectivity: 4x USB 3.0, 2x GMSL2, 2x PoE GbE ports
- Wide range 9~36V DC power input
- Optional wireless: Wi-Fi 6E and 4G LTE / 5G with Nano SIM
- Optional Out-of-Band (OOB) management support
The DFI X6X-ORN is a compact, IP67-rated fanless edge AI system powered by the NVIDIA® Jetson Orin Nano™ or Orin NX module. Built for harsh outdoor and industrial environments, it delivers reliable AI inference performance with a ruggedized enclosure, wide-range DC power input, and an extended -20°C to 60°C operating temperature. Its rich connectivity — including GMSL2 camera interfaces, PoE ports, USB 3.0, CAN Bus, and optional 5G — makes it ideal for intelligent transportation, smart surveillance, and autonomous mobile robotics.
Specifications Summary
| Processor System | SOM | NVIDIA® Jetson Orin Nano™ 4GB / 8GB, Orin NX 8GB / 16GB |
|---|---|---|
| CPU | 6/8-core Arm® Cortex®-A78AE v8.2 64-bit | |
| GPU | Up to 1024-core NVIDIA Ampere GPU with 32 Tensor Cores | |
| AI Performance | Up to 70 TOPS (Orin NX 16GB, MAXN SuperMode) | |
| Memory | Capacity | 4GB / 8GB / 16GB LPDDR5 |
| Storage | M.2 | M.2 2242/2280 M-Key (NVMe) |
| Network | LAN Ports | 4x GbE RJ-45 (Intel i210); 2x support PoE 802.3af (max. 15W each) |
| Camera Interface | 2x GMSL2 (FAKRA SMB Plug Z code) | |
| I/O Interfaces | USB | 2x USB 3.0 M20, 2x USB 2.0 M20, 1x USB 2.0 M20 (recovery) |
| Display | 1x HDMI M20 | |
| CAN Bus / COM | 1x M23 A Code (RS232 Tx/Rx, CAN Bus 2.0, 4x GPI & 4x GPO) | |
| SIM | 1x Nano SIM card slot M20 | |
| Expansion | Wireless | 1x M.2 E-Key 2230 (Wi-Fi 6E), 1x M.2 B-Key (4G LTE / 5G) |
| OOB | Optional Out-of-Band (OOB) management support | |
| Power | Input Voltage | 9~36V DC (1x M12 B Code 5-pin connector) |
| OS Support | Linux | JetPack 6.2 |
| Environment | Operating Temp. | -20°C to 60°C |
| Storage Temp. | -40°C to 85°C | |
| Humidity | 5 ~ 95% RH (non-condensing) | |
| Mechanical | Dimensions | 237 x 194 x 105.3 mm |
| Weight | 5.2 kg | |
| Mounting | Wall mount (brackets and screws included) | |
| Protection | IP67 enclosure | |
| Certifications | Standards | CE, FCC Class A, RoHS |
