5MP Rolling shutter low luminance capture Processed images with built-in Vizionlink™ ISP technology.
ISP
Processed images with built-in Vizionlink™ ISP technology.
Specification
| Sensor Information |
| CMOS Sensor | ON Semi AR0521 | | Active Pixels | 2592(H) x 1944(V) | | Pixel Size | 2.2µm x 2.2µm | | Optical Format | 1/2.5″ (Diagonal 7.13mm) | | Shutter Type | Rolling Shutter | | Chromaticity | Mono / Color | | Maximum Frame Rate | 5MP @ 60 FPS | | Chief Ray Angle | 9° | | Input Clock Range | 10 – 48 MHz | | Bit Depths | 8 / 10 / 12 bit | |
| Certification and Compliance |
| Certification | Compliant with CE / FCC / RoHS / REACH directives | |
| Environmental and Mechanical |
| Dimensions | 26.5 x 26.5 mm | | Relative Humidity | 10 to 90 % | | MTBF | 50,000 Hours | | Shock | 15G half-sine 11 ms duration | | Operation Temperature | Industrial: -30° to +85° C | | Vibration | 1 Grms random 5-500Hz hr/axis | | Weight | 5 grams | |
| Shop Data |
| Brand | TechNexion | | Country of Origin | Taiwan | | HTSN | 8525.80.5050 | | ECCN | EAR99 | | REACH / RoHS | YES | |
