Mura MPX-V16

Matrox Mura MPX Series

Mura MPX-V16

Matrox Mura MPX Series

Redefine Your Video Wall Experience

The Matrox Mura MPX-V16 video wall controller board makes no compromises as it redefines the future of collaborative video walls and wall matrix management. The unique single-slot board design captures up to 16 NTSC/PAL/SECAM video input channels using a PCI Express x4 Gen1 board—leveraging 8 Gbit per second data transfer—and supports adaptive de-interlacing. The Mura MPX-V16 video capture card can be combined with other Matrox Mura MPX Series boards to create tailored video wall solutions with support for additional digital and analog video, as well as SDI video inputs.


  • Capture up to 16 NTSC/PAL/SECAM video input channels with a single board
  • Combine multiple Matrox Mura MPX Series boards to drive desired channel requirements—all from a single system
  • PCI Express x4 Gen1 host bus connection leverages 8 Gbit/s data transfer
  • Support for NTSC/PAL/SECAM (S-Video, Composite) input resolutions
  • Designed for control roomsoperation centers and other mission critical environments as well as digital signage, and presentation systems that require stable, reliable video wall technology
  • Pair Mura IPX Series with Mura MPX boards in Matrox-certified platforms for 4K capture and multi-stream H.264 level 5.2 encoding/decoding over standard IP onto video walls up to 56 displays and a more favorable input-to-output ratio
  • High-density analog SD video capture card works with Matrox Mura MPX-4/4, MPX-4/2, MPX-4/0 and MPX-SDI output capture boards
  • Hardware Framelock: Synchronization of multiple outputs provides tear-free display of captured video sources across multiple displays
Hardware included
  • Mura MPX-V16 board
  • 2 breakout cables with DVI-A to 16x BNC connectors
  • 1 Framelock cable

Matrox MuraControl software and APIs

Easy-to-use video wall management software

Matrox MuraControl is a low-cost, premium performance, video wall management software that provides an easy and intuitive way to manage your Matrox-based video wall, multiviewer, or personal video wall locally or remotely. Available as a feature-rich, single-licence software for Microsoft® Windows® or as a free, lighter version app for iPad® with drag & drop functionality, it can be used to create and manage layouts offline or in real time.

Matrox Mura SDK and re-branding options

Matrox offers a complete range of software, APIs, and libraries that allow OEMs and developers to build personalized applications or interfaces based on project needs. White-label options allow for easy re-branding of Matrox software with enterprise naming, logos, colors, and identity for complete corporate integration.


Control rooms, Corporate enterprises, Education, Worship, Large venue, Entertainment, Security/Surveillance

Control rooms/Operation centers
Mura MPX Series boards are the ultimate building blocks for display wall controllers for process control, surveillance, network operation centers, and other control room environments.
Presentation/Digital signage
Mura MPX Series offers the competitive edge and scalability required for presentation systems in corporate boardrooms and conference rooms and digital signage installations in small and large venues. Combined with an off-the-shelf application or integration of the remote control interface using the network API, Mura MPX Series helps get your message out more effectively.
Matrix switcher/Video scaler/Video converter
Mura MPX Series’ unique multi-functional board design facilitates matrix switching, signal conversion, video scaling and de-interlacing in a single board, eliminating the need to purchase separate solutions.
