LNA-8000NC
8000 Single-Band C-Band LNA
Norsat’s LNA’s provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard C-Band LNAs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNAs. 8000 Series.
KEY SPECIFICATIONS
| Product Family | 8000 Series |
| Band | C-Band |
| Noise Figure | 30 K |
| Input Frequency – Band 1 | C-Band: 3.40 – 4.20 GHz |
RF SPECIFICATIONS
| Conversion Gain | 50 dBm |
| Gain Variation over operating band | 4.0 dB p-p |
| Input VSWR | 2.5 : 1 |
| Output VSWR | 2.0 : 1 |
| Output P1dB compression point | 5 dBm |
ELECTRICAL SPECIFICATIONS
| Power Requirements | 15 – 24 V |
| Current Drain | 100 mA |
INTERFACE SPECIFICATIONS
| RF Input Connector | CPR 229G waveguide grooved |
| RF Output Connector | N-50 Ohm |
M & C SPECIFICATIONS
| Input Power Port | DC Power via SM or N |
ENVIRONMENTAL SPECIFICATIONS
| Temperature – Operational | -40 to +60°C |
| Humidity | 0 – 95% |
PHYSICAL SPECIFICATIONS
| Dimensions (L x W x H) | 180 x 100 x 70 mm |
| Weight | 425 g |
