FS-1011
Fanless Desktop for Mini-ITX
Fanless Desktop for Mini-ITX
Specifications
| Model Number | FS-1011 |
| RoHS Compliance | Yes |
| Standard Drive Bays | Internal Drive Bay : 2.5″ HDD x 1 |
| Front Panel | Power SW. Power LED. HDD LED. USB 2.0 Port x2. |
| Back Panel | Expansion PCI/PCI-E Raw slot x1. USB 3.0 Port x4. VGA x 1. COM port x6. HDMI x1. Gigabit LAN x 2. Display Port x2 Audio IN/OUT. 12V DC in. |
| Mother Board: | For IMB-194-L Mother |
| External Adapter Input | C7(80W) |
| Dimensions (WxHxD) | 6.50″ x 9.00″ x 10.30″ 165.1 mm x 228.6 mm x 261.6 mm |
