AIR-030
Edge AI Inference system powered by NVIDIA® Jetson AGX Orin™
Advantech AIR-030 – AI Inference System Based on NVIDIA® Jetson AGX Orin™
- Compact and high-performance AI box up to 275 TOPS AI computing
- Powered by NVIDIA Jetson AGX Orin 32GB/64GB modules
- 9~36V wide power and -10~60°C extended operating temperature
- Multiple I/O ports: 3x 2.5GbE LAN, 4x COM, CANBus, DIO, USB 3.2 and Type-C
- Versatile expansions: M.2 B-Key, E-Key, M-Key (NVMe) and PCIe x16 (optional)
- Pre-loaded with Ubuntu 20.04 and JetPack 5.0 SDK (AWS Greengrass Certified)
Advantech’s AIR-030 is a high-end edge AI system powered by the NVIDIA Jetson AGX Orin module. Featuring a robust design, it delivers energy-efficient, powerful AI inferencing up to 275 TOPS. The system supports wide voltage input and extended operating temperatures, making it an ideal industrial-grade solution for advanced edge AI and robotics applications.
Specifications Summary
| Processor System | CPU | 12-Core / 8-Core NVIDIA Arm® Cortex A78AE v8.2 |
|---|---|---|
| GPU | NVIDIA Ampere architecture with up to 64 Tensor Cores | |
| AI Performance | Up to 275 Sparse TOPS (INT8) | |
| Memory | Capacity | 64GB / 32GB 256-bit LPDDR5 DRAM |
| Network | LAN Ports | 3x 2.5GbE (Intel I225-LM) |
| I/O Interfaces | USB & Display | 4x USB 3.2 Gen2, 1x USB Type-C, 1x HDMI |
| COM, DIO & CAN | 4x RS-232/422/485, 16-bit DIO, 2x CANBus | |
| Expansion | Slots | 1x M.2 2280 NVMe, 1x M.2 2230, 1x M.2 3052, Optional PCIe x16 |
| Environment | Operating Temp. | -10 ~ 60 °C (32GB) / -10 ~ 50 °C (64GB) |
| Mechanical | Dimensions | 200 x 220 x 74 mm |
